Short length & Compact design

Strong airflow despite the short length of 790mm.

Easy Programming

For easy operation programming, the user can choose either start-end (On-Off) or end-start (Off-On) times, depending on his needs from 30 minutes to 12 hours (every 30 minutes).

Maximum Power Mode

The desired internal temperature is quickly achieved with the rapid cooling or rapid heating function. The device operates continuously for approximately 20 minutes, at maximum compressor and fan speed.

Specifications

Rated Output Btu/h: 18000

Cooling Energy Class: A++

Heating Energy Class (Warm Zone): A+++

Heating Energy Class (Middle Zone): A+

Warranty 3 years for all parts without limitations and an additional 7 years for the compressor

Mode of Operation: P/T

Operating Voltage V-Hz-Ph: 230V, 1Ph, 50Hz

Cooling Efficiency Btu/h: 5.2(0.9-5.5)/17750(3070-18770)

Thermal Efficiency Btu/h: 6.3(0.6-6.6)/21500(2050-22500)

Seasonal Energy Efficiency Rating (SEER) Cooling: 7.20

Seasonal Coefficient of Performance (SCOP) Heating (Average): 4.30

Seasonal Coefficient of Performance (SCOP) Heating (Heat): 6.30

Indoor Unit Dimensions (H x W x D) mm: 293x790x249

Outdoor Unit Dimensions (H x W x D) mm: 542x799x290

Liquid/Gas Piping Diameter mm: 6.35 / 9.52

Maximum piping length / Maximum height difference m: 25 (15)/20

Operating Temperature Range Cooling °CDB: -10 ~ 46

Operating Temperature Range Heating °CDB: -15 ~ 24

Consumption Cooling/Heating kW: 1.68/1.80

Annual Energy Consumption Cooling kWh/annum: 253

Annual Energy Consumption Heating (Average/Heat) kWh/annum: 1563/556

Dehumidification L/h: 1.9

Air Supply m³/h (H) Indoor / Outdoor Cooling: 865/1830

Air Supply m³/h (H) Indoor / Outdoor Heating: 995/2265

Sound Pressure Indoor Unit Cooling dBA (H/M/X/A): 47 / 44 / 40 / 35

Sound Pressure Indoor Unit Heating dBA (H/M/X/A): 50 / 45 / 41 / 37

Sound Pressure of Outdoor Unit Cooling/Heating dBA (H): 50 / 56

Indoor Unit Sound Power Cooling/Heating dBA (H): 60 / 65

Sound Power of Outdoor Unit Cooling/Heating dBA (H): 61 / 66

Indoor Unit Net Weight kg(lbs): 9.5 (21)

Outdoor Unit Net Weight kg(lbs): 33 (73)
